Moisture: 30% to 70% RH
Conductor stripped length: 6 to 7 mm / 0.24 to 0.28 in
Conductor cross-section: 0.5 to 2.5 mm² / 20 to 14 AWG (solid, stranded, and bootlace)
Max. altitude: 2000 m / 6562 ft
Max AC switching voltage: 240 V
Max DC switching voltage: 30V
Max AC switching current: 2A
Max DC switching current: 2A
Mounting: DIN rail, attached to a Shelly Pro 3EM
Ambient temperature: -20 °C to 40 °C / -5 °F to 105 °F
Enclosure material: Plastic
Screw terminal maximum tightening torque: 0.4 Nm / 4.43 lbin
Power consumption: < 1 W
Power supply voltage DC: 3.3 V and 12 V (from Shelly Pro 3EM unit)
Size (HxWxD): 94x19x69 ±0.5 mm / 3.70x0.75x2.71 ±0.02 inches
Weight: 20 ±1 g / 0.70 ±0.05 oz
3800235268131EAN:
